| Modelljahr |
2012 |
| Rahmen |
28" E-Bike, Alloy 6061 Lite Tubing, Hydroformed Tubings, Butted, 3D Dropout, E-Bike-Comfort Geometry |
| Gabel |
Trekking Rigid Fork, Alloy Steerer |
| Bremsen |
Shimano XT, BR-M785, hydraulic Disc-Brake, 180/160mm |
| Bremshebel |
Shimano XT, BL-T785 |
| Schaltung |
Shimano Deore XT, RD-T780, Top Normal
|
| Schalthebel |
Shimano Deore XT, SL-T780, Rapidfire-Shifter |
| Grössen |
48/52/56/60cm |
| Farben |
black-grey matt |
|
| Felgen |
Alex TA19, 622-19, Disc, eyelets, 32H |
| Reifen |
Schwalbe Energizer Pro, 40-622, with reflective stripe |
| Naben |
V: Shimano Sport hub dynamo, DH-T785, Center-Lock, Disc, Quick Release, H: Shimano XT, FH-M785, Center-Lock, Disc, Quick Release |
| Speichen |
stainless, black Color |
| Beleuchtung |
Busch & Müller Lumotec IQ Cyo T, senso plus, with 24h Daylight Function |
| Rückleuchte |
Busch & Müller Toplight Mini Plus, standlight |
| Bleche |
Curana C-Lite, Alloy Sandwich, width: 45mm, with integrated Headlightholder |
| Ständer |
Atran Stylo HV |
| Gepäckträger |
Racktime Light IT, Bergamont Custom Version |
| Innenlager |
Bosch |
| Kurbelsatz |
BGM Pro, with Alloy Cover, length: 170mm |
| Zahnkränze |
Sram PG-1050, 11-32t |
| Kette |
Shimano CN-HG54 |
| Sattel |
Selle Royal Freccia Lookin |
| Sattelstütze |
BGM Pro, 2-Bolt Design, 27.2mm, length: 350mm |
| Lenker |
BGM Pro, Riserbar, sweep: 9°, rise: 15mm, width: 620/640/660mm for 48/52-56/60cm |
| Vorbau |
BGM Comp 17°, length: 90/100/110mm for 48/52/56-60cm, Barbore 25.4 |
| Griffe |
BGM Comfort, Ergo, Double Density, Clamp Version |
| Steuersatz |
FSA ZS-4, ZS44/28.6 | ZS44/30 (1 1/8") |
| Pedale |
Wellgo C33 |
| Gewicht |
20,9kg (48cm, ohne Akku) |
|
